28
INSTRUMENTS
Trim Meter
(optional equipment)
Trim Tab
Engine Cover Latch
CONTROLS AND FEATURES
TRIM METER
TRIM TAB
TIGHTENING
BOLT
U
U
N
N
L
L
O
O
C
C
K
K
ENGINE COVER LATCH
When the trim tab is correctly
adjusted (p.
), steering effort is
equal in either direction.
If uncompensated, torque steer would
make the outboard motor tend to turn
to one side.
The trim tab compensates for
‘‘torque steer’’, which is a reaction of
the outboard motor to propeller
rotation.
The engine cover latch fastens the
engine cover to the outboard motor.
The trim meter indicates the relative
trim angle of the outboard motor.
Refer to the trim meter when using
the power trim/tilt switch to achieve
the best performance from the boat.
