Page 68 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
D. Service Parts
Beginning Manufacturing Date: 2-17-03
Ending Manufacturing Date:
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your appliance please provide
model number and serial number. All parts listed in this manual may be ordered from an authorized dealer .
Constitution FP
Stocked
at
Depot
Item Description Part No. Comments Serial
Number and
Date
Outside Air Shield 33271 Y
Outside Air Termination Cap, 6 in. 480-1160
Slider Control Assembly 480-5410
Snap Disc, Ceramic 480-1730 Y
13 Spring Handle, Door, 1/2 in., Gold 832-0620
Spring Handle, Door, 1/4 in., Gold 832-0630
Starter Plate Assembly, 8 inch. SL1
4 Timer Assembly 480-5150
Timer, Mechanical, 12 hr. SRV480-1940 Y
3 Wire Harness SRV480-0990 Y
