Heatilator • ADI-ZCFB-S • 2032-910 Rev. G • 9/08
36
ADI-ZCFB-S
Service Parts
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for
your appliance please provide model number and serial number. All parts listed in this manual may
be ordered from an authorized dealer.
Stocked
at Depot
ITEM
DESCRIPTION
COMMENTS
PART NUMBER
Log Set Assembly
LOGS-2031
Y
1
Log 1
SRV2032-701
2
Log 2
SRV2032-702
3
Log 3
SRV2032-703
4
Log 4
SRV340-704
5
Log 5
SRV340-705
6
Log 6
SRV740-707
7
Access Plate: Fan
2019-111
8
Air Passage: Slide Plate Assembly
2019-096
Slide Plate Handle
2019-201
9
Air Baffl e
2019-165
10
Burner Key
2019-166
11
Burner
2031-003
Y
12
Burner Drop Plate
2019-164
13
Log Grate
2019-006
14
Glass Door Assembly, Ceramic
GLA-2019
Y
15
Surround Mount, Right
2019-205
Surround Mount, Left
2019-196
16
Access Plate
2019-116
Junction Box
040-250A
Y
Glass Latch, Right
QTY 2 Req.
386-122A
Y
Glass Latch, Left
QTY 2 Req.
339-121A
Y
Vent Pipe Assembly
768-380A
Wire Assembly
2020-069
Y
Mineral Wool Embers
050-721
Vermiculite Embers
MYSTIC-EMBERS
Thermocouple
2103-511
Y
Thermopile
2103-512
Y
Pilot Tube
SRV485-301
Y
Patch Kit
SRV-PACK
Conversion Kit NG
NGKS-FBZC
Y
Conversion Kit LP
LPKS-FBZC
Y
Pilot Orifi ce NG
2103-116
Y
Pilot Orifi ce LP
2103-117
Y
Regulator NG
230-1570
Y
Regulator LP
230-1520
Y
Additional service parts on following page.
