Heatilator • ADI-ZCFB-S • 2032-910 Rev. G • 9/08 19
Figure 9.4 Fan Wiring Diagram
JUNCTION BOX
VARIABLE SPEED CONTROL
TEMPERATURE
SENSOR SWITCH
WHT
GRN
BLK
BLK
110-120 VAC
BLOWER
BLOWER RECEPTACLE BLK
BLK
BLK
BLK
WHT
GROUND
WHT
BLK
BLK
BLK
REMOTE
RECEPTACLE
INSERT STUD THROUGH HOLE
AND SECURE WITH WING NUT
WING
NUT
TEMP SWITCH
BRACKET
FAN
TEMPERATURE
SENSOR SWITCH
SPEED CONTROL
(RHEOSTAT)
REMOTE
OUTLET FAN
OUTLET
BEND UP
TABS
JUNCTION BOX
NOTE: If any of the original wire as supplied
with the appliance must be replaced, it must be
replaced with type 105º crated wire.
NOTE: Do NOT install blower if using operable
glass doors.
