Replacing the system board – HP VLI 8 PC User Manual
Page 30
2 How to Install and Replace Components In Your Desktop PC
Replacing the System Board
72
Replacing the System Board
1 Remove the computer’s cover (described in this chapter).
2 Remove the lower bracket.
3 Remove the main memory and processor from the old system board
(described in this chapter).
4 Remove the old system board.
