Connection (continued), Connecting procedure (continued) – Hitachi 26LD9000TA User Manual
Page 16
16
CONNECTION (continued)
Connecting Procedure (continued)
Monitor Out can be used to display same image as main unit on another television.
When this output terminal is connected to an external television with a 75 Ohm terminal, the same image from composite
(AV1, AV2), or RF signal can be displayed to the external television.
Sub Woofer terminal can bring the deep bass sound from the external speaker.
PC terminal (D-sub 15 pin or audio) is connected to PC, which allows Analog RGB signal.
IN
OUT
(Example)
VCR
IN
OUT
(Example)
(Example)
OUT
IN
or
Mini
stereo
plug
or
