380976 V3.2 4/11 19
M Ω (Resistance)
Range Resolution Accuracy Overload Protection
9.999MΩ 1KΩ
99.99MΩ 10KΩ
±(5% + 10d) 600V
Capacitance
Range Resolution Accuracy Overload Protection
10.000 μF 1nF
100.00 μF 10nF
1000.0 μF 100nF
±(1.5% + 5d)
7000 μF 1μF ±(4.5% + 15d)
600V
Diode (Continuity <40mV)
Range Resolution Accuracy Overload Protection
2.000V 1mV ±(2% + 1d) 600V
Temperature (K-Type thermocouple)
Range Resolution Accuracy Overload Protection
-50 o C to 900 o C 0.1 o C ±(1% + 1 o C)
-58 o F to 1000 o F 0.1 o F ±(1% + 2 o F)
30V
AC
or 60V
DC
1Φ/3Φ TRUE Power (PF > 0.5 or K < 60 o ) (50/60Hz)
Range Resolution Accuracy Overload Protection
60.00KW (<100A) 10W ±(5% + 20d)
600.0KW (>100A) 100W ±(5% + 20d)
600VAC/
1000AAC
1Φ/3Φ Horse Power (HP) (PF > 0.5 or K < 60 o ) (50/60Hz)
Range Resolution Accuracy Overload Protection
80.00HP (<100A) 0.01 HP ±(5% + 20d)
800.0 HP (>100A) 0.1 HP ±(5% + 20d)
600VAC/1000AAC
1Φ/3Φ Reactive Power (KVAR) (PF > 0.5 or K < 60 o ) (50/60Hz) K
Range Resolution Accuracy Overload Protection
60.00KVAR (<100A) 10VAR ±(5% + 20d)
600.0KVAR (>100A) 100VAR ±(5% + 20d)
600VAC/
1000AAC
