Hoshizaki DCM-300BAH(-OS) - Manual (Page 6)

6
MODEL NUMBER DCM-300BAH-OS
SERIAL NUMBER
AC SUPPLY VOLTAGE 115-120/60/1
COMPRESSOR 120V 7.9RLA 39.0LRA
GEAR MOTOR 120V 1.45FLA 80W
FAN MOTOR 115V 0.8FLA 16W
AGITATING MOTOR 120V 0.9FLA 55W
DISPENSING MOTOR 120V 0.9FLA 55W
OTHER 120V 0.2A
MAXIMUM FUSE SIZE 20 AMPS
MAX. HACR BREAKER (USA ONLY) 20 AMPS
MAX. CIRC. BREAKER (CANADA ONLY) 20 AMPS
MINIMUM CIRCUIT AMPACITY 20 AMPS
DESIGN PRESSURE HI-460PSI LO-290PSI
REFRIGERANT 404A 15.9 OZ.
2. DCM-300BAH-OS (air-cooled)
The rating label and nameplate provide electrical and refrigerant data. The rating label can
be seen by removing the front panel. The nameplate is located on the rear panel.
We reserve the right to make changes in specifications and design without prior notice.
HOSHIZAKI ICE MAKER
MOTOR-COMPRESSOR THERMALLY PROTECTED
NOT INTENDED FOR OUTDOOR USE!
Hoshizaki America, Inc.
Peachtree City, GA
www.hoshizaki.com
For certification marks, see the nameplate
on the rear panel.
