Hoshizaki FD-1001MRH(-C) User Manual
Page 3

3
CONTENTS
Important Safety Information ................................................................................................. 5
I. Specifications ...................................................................................................................... 6
1. FD-1001MAH(-C) (air-cooled) .................................................................................. 6
2. FD-1001MWH(-C) (water-cooled) ............................................................................ 7
3. FD-1001MRH(-C) (remote air-cooled) ...................................................................... 8
4. FD-1001MLH(-C) (low-side, parallel rack system) ................................................... 9
1. FD-1001MAH(-C) (air-cooled) ................................................................................ 10
2. FD-1001MWH(-C) (water-cooled) ...........................................................................11
3. FD-1001MRH(-C) (remote air-cooled) .................................................................... 12
4. FD-1001MLH(-C) (low side, parallel rack system) .................................................. 13
A. Checks Before Installation ........................................................................................... 14
B. How to Remove Panels ............................................................................................... 14
C. Location ...................................................................................................................... 15
D. Setup ........................................................................................................................... 15
E. Electrical Connection .................................................................................................. 16
F. Installation of Remote Condenser Unit ........................................................................ 17
1. Checks Before Installation ...................................................................................... 17
2. Location ................................................................................................................. 17
3. Setup ..................................................................................................................... 18
4. Line Set ................................................................................................................. 18
5. Electrical Connection ............................................................................................. 21
6. Stacking Remote Condenser Units ........................................................................ 22
1. Icemaker ................................................................................................................ 27
2. Water-Cooled Condenser....................................................................................... 28
I. Final Checklist ............................................................................................................. 30
J. Startup ......................................................................................................................... 31
K. Bin Control Check ....................................................................................................... 32
1. Infrared Sensor Check ........................................................................................... 32
2. Mechanical Backup Bin Control Check .................................................................. 34
3. Infrared Sensor Shutdown Delay ........................................................................... 35
IMPORTANT
This manual should be read carefully before the icemaker is installed and
operated. Only qualified service technicians should install, service, and
maintain the icemaker. Read the warnings contained in this booklet carefully as
they give important information regarding safety. Please retain this booklet for
any further reference that may be necessary.
