Page 36
34
Fuel Priming Bulb
(optional equipment)
CONTROLS AND FEATURES
PRIMING BULB
UP
OUTLET END
(motor side)
INLET END
(tank side)
VENT KNOB
C
C
L
L
O
O
S
S
E
E
O
O
P
P
E
E
N
N
FUEL FILLER CAP
Fuel Filler Cap Vent Knob
A priming bulb is built into the fuel
hose that connects the fuel tank to the
outboard motor.
Before starting the engine, hold the
priming bulb up in the direction of
the arrow; then squeeze the priming
bulb until it feels firm. This will
ensure that fuel is supplied to the
engine (p.
The cap is provided with a vent knob
to seal the portable fuel tank for
carrying it to and from the boat.
Open the vent knob 2 or 3 turns
before starting the engine.
08/02/28 10:40:07 31ZZ4600_035
