Specifications, Technical and consumer information, 113 specifications – HONDA BF50D User Manual
Page 115

BBDJ
BF40D
29.8 kW (40 HP)/5,500 rpm
5,000
6,000 rpm
4 stroke OHC in-line 3 cylinder
49.3 cu-in (808 cm )
8°, 12°, 16°, 20°, 24°
4° to 12° (when Transom angle is 12°)
35° right and left
Dog type (Forward-Neutral-Reverse)
mechanical type
Water exhaust
Water cooling with thermostat
12V
17A
ULTRA · LOW EMISSION
0.43 US qt (0.41 )
2.2 US qt (2.1 )
2.1 US qt (2.0 )
API standard (GL-4) SAE 90
outboard motor gear oil
Trochoid pump pressure lubrication
Full transistor battery
Electric starter
Tiller handle
LRT
27.3 in (694 mm)
31.3 in (794 mm)
216 lbs (98 kg)
220 lbs (100 kg)
electrical type
Motor-mounted,
remote control
0.024
0.028 in (0.6
0.7 mm)
53.7 in (1,364 mm)
20.5 in (521 mm)
LH
14.6 in (372 mm)
API standard (SG, SH, SJ)
SAE 5W-30
DR7EB (NGK)
X22ESR-UB (DENSO)
Unleaded gasoline
(86 pump octane or higher)
63° (when Transom angle is 12°)
Gear case:
Engine:
Engine:
Gear case:
without oil filter change
with oil filter change
Low pressure side:
High pressure side:
,
113
Specifications
TECHNICAL AND CONSUMER INFORMATION
MODEL
Type
Description
Code
Overall length
Overall width
Overall height
Rated power
Full throttle
range
Engine type
Displacement
Transom angle
Steering angle
Gear change
Fuel
Fuel pump
Spark plugs
Exhaust system
Cooling system
D.C. output
CARB star label
Oil capacity
Specified oil
Lubrication
system
Ignition system
Starter system
Steering
control
system
Transom height
(when transom
angle is 12°)
Dry weight
Trim angle
Tilt up angle
Spark plug gap
Without battery cable, with propeller
Honda outboards are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
