CONTROLS AND FEATURES

MANUAL RELIEF VALVE

MANUAL
(To release)

RIGHT STERN BRACKET

POWER
(To fix)

Manual Relief Valve

The outboard motor can be tilted
manually after opening the manual
relief valve. This allows the outboard
motor to be tilted up or down when
no battery is connected.

Check that nobody is under the
outboard motor before opening the
manual relief valve. If the manual
relief valve is loosened (turned
counterclockwise) when the outboard
motor is tilted up, the outboard motor
will suddenly tilt down.
