111-2133 Rev B
Briggs and Stratton 126T05-1840-B1
E3
Crankcase Assembly
Ref Part No. Qty. Description
Sump-Engine 4 493279 1 o
Gasket-Crankcase (.015 STD) 12 692232 1 oq
Plug-Drain, Oil 15 691680 1 o
Seal-Oil 20 399781s 1 oq
Screw (Engine Sump) 22 691092 1 o
Slinger-Oil, Governor 43 691997 1 o
Camshaft 46 691449 1 o
Sump-Engine 48 792742 1 o
Screw (Dipstick Tube) 287 690940 1 o
Dipstick 523 499621 1 o
Seal, O-Ring (Dipstick Tube) 524 692296 1 oq
Tube-Dipstick 525 495265 1 o
Seal, O-Ring (Dipstick Tube) 842 691031 1 oq
Dipstick Tube ASM 847 692047 1 o
12
