Hustler Turf FasTrak 36" & 42" Decks none - Manual (Page 17)

333559 09/08 3-5
Hydro Transmission Installation S/N Prior To 07091558
NOTES:
1. Torque to 17 ft.-lbs.
2. Install using existing hardware on EZT.
3. Do not torque, item 17 (Pump Belt Idler Arm) must pivot freely.
4. Hydro transmission service parts:
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 710087 710087 8 CS .312-18 X 2.50 HX G5 ZNYC
2 028118 028118 2 FW .62 X 1.00 X .134 ZNYC
3 794404 794404 1 PULLEY
4 025007 025007 2 CS .625-11 X 1.75 HX G5 ZNYC
5 793836 793836 1 A-SECTION PUMP BELT
6 792911 792911 1 EZT LEFT PUMP/MOTOR COMBO
7 792895 792895 1 EZT RIGHT PUMP/MOTOR COMBO
8 718288 718288 1 FW .516 X .875 X .09 ZNYC
9 035238 035238 1 LW .437 MED SPRING ZYNC
10 794552 794552 1 NT .375-16 HXZY NL
11 335695 335695 1 SPACER TUBE-EZT MINI FST
12 768523 768523 12 FW .343 X .687 X .051/.080 HD ZNYC
13 034272 034272 8 NT .312-18 HX G5 ZNYC
14 784827 784827 1 4.00"OD, 5/8"ID IDLER PULLEY
15 781153 781153 2 UHMW BUSHING
16 025296 025296 2 FW .760 X 1.625 X .08 ZNYC
17 324046 324046 1 PUMP BELT IDLER ARM
18 061101 061101 1 NT .750-10 HX NL ZN
19 036384 036384 1 IDLER SPRING
20 364315 059931 1 SPRING CHAIN
21 335893 335893 2 BELT DEFLECTOR
PART NUMBER
PRIOR TO
SERIAL NUMBER
06081543
DESCRIPTION
PART NUMBER
SERIAL NUMBER
06081543
DESCRIPTION
792013 AXLE NUT 788877 AXLE NUT
794982 FAN, EZT 794974 EZT PULLEY KIT
795005 RIGHT EZ CAP-VENT ASSY 795039 LEFT EZ VENT TUBE ASSY
795013 EZT NUT, SPECIAL 791723f FW .530 X 1.63 X .06 SLO
795021 HUB ASSEMBLY 788232 HUB ASSEMBLY
795047 PARKING PAWL KIT, EZT 798363 PARKING BRAKE GEAR
795054 90 DEG VENT FITTING 795062 RIGJHT EZT VENT HOSE
798371 RETAINING RING 792929 PULLEY/FAN COMBO 36/42
3
