Slide belt side of agitator into

place, pushing the agitator slightly

to left, pulling it forward and then
down.

Roll agitator to make sure belt is

positioned properly.

The cover attaches at the front of
the nozzle. Place the notched
edge at the front of the cover into
the groove in the nozzle base.

While maintaining front connec-
tion, rotate cover over nozzle base
and pull nozzle cord through

opening in cover.

Turn nozzle over and replace
screws.

15
