Technical specifications - hard drive controllers, Quickspecs, Hp xw9400 workstation – HP XW9400 User Manual

Page 40

Integrated LSI SAS 1068E

Integrated LSI SAS 1068E
Controller with RAID 0, 1,

Controller with RAID 0, 1,

Controller with RAID 0, 1,
1E/10E

1E/10E

PCI Bus

PCI-Express x8 lanes

PCI Modes

Bus Master DMA

RAID Levels

RAID 0, 1, 1E and 10E

PCI Data Burst Transfer

PCI Data Burst Transfer
Rate

Rate

8 PCI-Express lanes at 2.5Gbps in each direction for a total bandwidth of
5.0Gbps for each full duplex lane. Total aggregate bandwidth of up to
4GBps possible.

Full Duplex

LSI's SAS1068E 8-port SAS/SATA controller supports 1.5 and 3.0Gb/s per
port data transfer rates.

PCI Card Type

N/A

PCI Voltage

N/A

PCI Power

N/A

Bracket

N/A

Certification Level

PCI-Express 1.0a

IO Bus

Eight 3Gb/s SAS/SATA ports

SAS Processor

LSISAS1068E

Internal Connectors

Four- SATA x1 connectors

External Connectors

None

Maximum Number of

Maximum Number of
SCSI Devices

SCSI Devices

LED Indicators

On-board activity and fault LEDs

Integrated Mirroring

Integrated Mirroring option available

LSI MegaRAID® SAS

LSI MegaRAID® SAS
8888ELP Host Bus

8888ELP Host Bus

8888ELP Host Bus
Adapter (HBA)

Adapter (HBA)

PCI Bus

PCI-Express x8 lanes

PCI Modes

Bus Master DMA

RAID Levels

RAID 0, 1, and 5
RAID spans 10 and 50

PCI Data Burst Transfer

PCI Data Burst Transfer
Rate

Rate

Up to 3Gb/s per port

Full Duplex

Up to 1.5 GB/s

PCI Voltage

+3.3V Add-in Card

PCI Power

7.5 Watts

Certification Level

PCI-Express 1.0a

IO Bus

Eight 3Gb/s SAS/SATA ports

Internal Connectors

Two SAS SFF8087 x4

External Connectors

Two SAS SFF8088 x4

Maximum Number of

Maximum Number of
SCSI DeviceS

SCSI DeviceS

LED Indicators

Connector LEDs indicate whether the internal or external connector is active
for ports 0-3 and 4-7

QuickSpecs

HP xw9400 Workstation

Technical Specifications - Hard Drive Controllers

DA - 12594 Worldwide — Version 27 — May 8, 2009
