Page 11

Possible Memory Configurations

Interfaces Supported

SATA

6 SATA interface (6 serial-ATA connectors), 8 SAS interface, 2 EIDE
interface (1 EIDE connectors) supported for optical drives.

Serial Attached SCSI

Serial Attached SCSI (RAID 0, 1, IME) or SATA 3 Gb/s (RAID 0, 1)

Chassis Fan Header

Front: One 3.15 x 0.98 inches; 80 x 25 mm)
Rear: One 4.72 x 0.98 inches; 120 x 25 mm (standard)

Power Supply

1050W custom power supply - (Wide Ranging, Active PFC)

Operating Voltage

Operating Voltage
Range

Range

1050W: 90 - 269 VAC

Rated Voltage Range

1050W: 100 - 240 VAC; 118 VAC

Rated Line Frequency

1050W: 50/60 Hz; 400Hz

Operating Line

Operating Line
Frequency Range

Frequency Range

1050W: 47 - 66 Hz; 393-407 Hz

Rated Input Current

1050W: 13.2 A @ 100-120VAC / 12.0A @ 118 VAC; 6.6 A @ 200-240 VAC

Heat Dissipation

1050W: Typical 3136 btu/hr (791 kg-cal/hr) ; Maximum 4480 btu/hr (1129 kg-cal/hr)

Power Supply Fan

92x32 mm variable speed

ENERGY STAR®

ENERGY STAR®
qualified

qualified

qualified (Config
Dependent)

YES

80 PLUS Compliant

YES

QuickSpecs

HP xw9400 Workstation

System Technical Specifications

DA - 12594 Worldwide — Version 27 — May 8, 2009

Page 11
