WaRnInG: THIs HeaTeR Is eqUIPPeD WITH

a THRee-PRonGeD GRoUnDInG PlUG THaT

sHoUlD be PlUGGeD DIReCTlY InTo a PRoP-

eRlY GRoUnDeD ReCePTaCle. Do noT CUT

oR ReMoVe THe GRoUnDInG PRonG fRoM

THe PlUG.

Terminal.strip.for.

thermostat.connec-

tion

Rear.view.of.Clarity

ConneCTInG THe CoRDseT

The.Clarity.B-Vent.Gas.Heater.must.be.installed.in.ac-

cordance.with.local.codes.or,.in.the.absence.of.local.codes,.

with.the.most.recent.edition.of.the.National.Electrical.Code.

ANSI/NFPA.70,.or.the.current.Canadian.Electrical.Code.

C22.1.

NOTE:.The.convection.fan.requires.a.120.VAC.supply.

for.operation,.but.the.heater.can.be.operated.without.the.fan.

as.in.the.case.of.a.power.outage.

Plug.the.3-prong.grounded.electrical.cord.plug.into.

the.wall.

ConneCTInG THe

oPTIonal THeRMosTaT

If.connecting.the.optional.thermostat,.it.must.be.plugged.

into.the.terminal.strip.located.on.the.left.side.near.the.bot-

tom.of.the.stove.

When. installing. a. millivolt. control. sys-

tem,. use. only. a. special. low. resistance. thermostat...

Do.not.use.a.regular.heating.thermostat.

Be.sure.that.all.electrical.connections.are.clean,.free.

from.corrosion,.and.tight..Inspect.connections.periodically.

to confirm that no corrosion has built up over time.

When. properly. installed. and. maintained,. a. millivolt.

control. system. should. give. many. years. of. trouble-free.

service.

It.is.important.to.use.wire.of.a.gauge.proper.for.the.

length.of.the.wire:

ReCoMMenDeD WIRe GaUGes

Maximum .

Wire

Length

Gauge.

100'.

14.

60'.

16.

40'.

25'.

15'.
