Parts.List
The.following.replacement.parts.for.your.Harman.Clarity.B-Vent.are.available.from.your.Harman.dealer.
ID# Part no. Part
1. 1-89-08270. BVG.weldment
2. 1-10-08262-1. Left.wing.door
3. 1-10-08262-2. Right.wing.door
4 3-40-08286 1/2" gas inlet flex
5. 3-40-08235. Rear.log
6. 3-40-08236. Front.log
7. 3-40-08237. Top.log
8. 3-40-08401. Ember.strip
9. 3-40-08232. Left.brick.panel
10. 3-40-08233. Right.brick.panel
11. 3-40-08234. Rear.brick.panel
12. 3-40-08224. Front.burner.tube
13. 3-40-08225. Center.burner.tube
14. 3-40-08226. Rear.burner.tube
15. 3-31-965487. Ext..spring
16. 3-40-00141. Formed.wire.gold.trim
17. 3-31-08225. Magnet
18. 3-20-408412. Snap.disc.fan.control
19. 2-00-4213. Snap.disc.fan.control.bracket
20. 3-20-326004. Power.cord
21. 2-00-4177. Lower.rear.access.cover
22. 3-42-2312. Glass.gasket
23. 3-44-1086405. 5/8".tight.knit.rope.for.door
24. 3-43-4103. Gold.plated.door.frame
25. 3-40-120. 13-3/4".X.19".glass
26. 3-40-121. 5-3/4".X.13-3/4".glass
27. 1-10-08285. Distribution.blower.w/ends
28. 3-44-08278. Pilot.tower.gasket
29. 3-40-820628. NG.valve
30. 3-40-82057. LP.valve
31 3-40-57356 #56 orifice, LP front/NG center
32 3-40-64347 #47 orifice, NG front
33 3-40-64739 #39 orifice, NG rear
34 3-40-57271 #71 orifice, LP center
35 3-40-57753 #53 orifice, LP rear
36 3-40-57753 #53 orifice, LP rear
37. 3-40-08231. Piezo.cable
38. 3-40-08229. Pilot,.NG
39. 3-40-08230. Pilot,.LP
40. 3-40-08228. Thermocouple
41. 3-40-08220. Piezo.ignitor
42. 3-31-08282. 90°.brass.elbow
43 3-31-08283 1/4" tp 3/8" male compression fitting
44 3-31-08284 3/8" tp 3/8" male compression fitting
45. 3-30-310056082. BHSCS.5mm.X.8mm.for.valve
46. 3-20-326006. 18".valve.harness
47. 3-20-326005. Harness.w/VSC
48. 3-20-08221. On-Off.rocker.switch
49. 3-20-08219. Thermopile
50. 2-00-08281. 3/8".tubing
51. 0-46-250. 1/4".tubing
52. 1-00-08513. Valve.change-over.assembly,.NG
53. 1-00-08314. Valve.change-over.assembly,.LP
54. 3-20-408411. Snap.disc.safety.switch
55. 2-00-42208. Rear.cover
56a. 2-00-42220. Snap.disc.safety.switch.bracket
56b. 2-00-42219. Snap.disc.safety.switch.heat.shield
57. 2-00-4169. Base.trim
58. 1-10-08265-1. Latch.arm,.left
59a. 1-10-08265-2. Latch.arm,.right
60a. 2-00-4138-1. Latch.cam,.left
60b. 2-00-4138-2. Latch.cam,.right
61. 1-10-08287. Front.door.assembly
62. 1-10-08258. Top
63. 2-00-42217. Draft.hood.heat.shield
64. 2-00-4162. Control.door
65. 2-00-4210. Control.heat.shield
66 2-00-4172 Baffle
. .
