Chapter 3 using the operator panel, Understanding the operator panel, Chapter 3 using the operator panel -1 – HP WP36/50 User Manual
Page 22: 1 understanding the operator panel -1, Ready - - - a4 plain
3-1
Chapter 3
Using the Operator Panel
This chapter explains the following topics:
• Understanding the Operator Panel
• Using the Operator Panel
The operator panel has an LCD message display, indicators, and eight keys.
Figure 3-1
1. Understanding the Operator Panel
ENTER
GO
CANCEL
MENU
READY
INTERFACE
SIZE
TYPE
DATA
ATTENTION
Ready
- - - A4 PLAIN
Message Display
(See
Interface Indicator
(See
)
Keys (See
)
Paper Size Indicator
(See
Paper Type Indicator
(See
)
Operation Indicators (See
