Harbor Freight Tools 95838 - Manual (Page 14)

Page 14 For technical questions, please call 1-800-444-3353. Item 95838
SAFET
y
Op
ERA
TION
M
AINTENAN
c
E
SETU
p
parts List and Diagram
pLEASE READ THE FOLLOWING cAREFULLy
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts List
Record product’s Serial Number Here:
Note: If product has no serial number, record
month and year of purchase instead.
Note: Some parts are listed and shown for
illustration purposes only, and are not available
individually as replacement parts.
part Description Qty
1 Label 1
2 Left Side Belt Cover 1
3 Left Housing 1
4 Nut M6 1
5 Ribbed Belt 1
6 Knife Pulley 1
7 Ball Bearing 6200 1
8 Knife Assembly 1
8a Knife Drum 1
8b Knife Holder 2
8c Knife 2
8d Knife Holding Bolts 6
8e Knife Adjustment Set Screw 4
9 Ball Bearing 628 1
10 Motor Pulley 1
11 Ball Bearing 608 2
12 Air Baffle 1
13 Rotor 1
14 Screw ST 4 x 55 2
15 Stator 1
16 Right Housing 1
17 Rabbet Depth Guide 1
18 Locking Knob 2
19 Right Side Cover 1
20 Label 1
21 Screw ST 4 x 16 17
22 Screw ST 4 x 20 2
23 Screw ST 4 x 10 6
24 Depth Adjustment Knob 1
25 Depth Knob Scale 1
26 Front Handle 1
27 Spring Ø5 x 20mm 1
28 Steel Ball Ø5 1
29 Front Cover 1
part Description Qty
30 Washer M4 1
31 Screw M4 x 16 2
32 Plastic Nut 1
33 Screw M4 x 30 2
34 Adjustment Bracket 1
35 Spring 1
36 Adjustable Base Plate 1
37 Fence 1
38 Wing Nut 1
39 Washer M6 1
40 Bolt M6 x 12 1
41 Fence Bracket 1
42 Plastic Insert 2
43 Rear Base Plate 1
44 Dust Bag Support 1
45 Dust Bag Strap 1
46 Dust Bag 1
47 Wrench Handle 1
48 Trigger 1
49 Wrench 1
51 Safety Switch 1
52 Spring Ø5.5 x 26 1
53 Exhaust Deflector 1
54 Spring Holder 1
55 Exhaust Direction Lever 1
56 Steel Ball Ø4 1
57 Spring Ø4 x 20 1
58 Cord Protector 1
59 Power Cord 1
60 Nylon Tie 1
61 Cord Retainer 1
62 Carbon Brush 2
63 Brush Holder 2
64 Brush Pressing Pad 2
