HP ProLiant Micro Server HP ProLiant Micro Server HP ProLiant Micro Server HP ProLiant Micro Server
Standard Memory
Standard Memory Standard Memory Standard Memory
1GB (1x1GB) of PC3-10600E DDR3 UDIMM Memory kit installed
Standard Memory Replaced with Optional Memory
Standard Memory Replaced with Optional Memory Standard Memory Replaced with Optional Memory Standard Memory Replaced with Optional Memory
Up to 8GB of memory is available with the removal of the standard 1GB of memory and the optional installation of 2 x 4 GB PC3-
10600E DDR3 UDIMM Memory kits.
NOTE: NOTE: NOTE: NOTE: The below chart does not represent all possible memory configurations.
Memory Memory Memory Memory Slot Slot Slot Slot
1A 1A 1A 1A 2B 2B 2B 2B
Standard Standard Standard Standard 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB Empty Empty Empty Empty
Optional Optional Optional Optional 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB Empty Empty Empty Empty
Optional Optional Optional Optional 2 GB 2 GB 2 GB 2 GB 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB
Optional Optional Optional Optional 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB Empty Empty Empty Empty
Optional Optional Optional Optional 4 GB 4 GB 4 GB 4 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
Maximum Maximum Maximum Maximum 8 GB 8 GB 8 GB 8 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Following are memory options available from HP: Following are memory options available from HP: Following are memory options available from HP: Following are memory options available from HP:
HP Memory HP Memory HP Memory HP Memory HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9
Memory Kit 593923-B21
HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9
Memory Kit 593921-B21
HP 1GB (1x1GB) Single Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9
Memory Kit 500668-B21
QuickSpecs
HP ProLiant MicroServer HP ProLiant MicroServer HP ProLiant MicroServer HP ProLiant MicroServer
Memory
DA - 13716 Worldwide — Version 10 — March 23, 2011 Page 14
