HP DC5000 User Manual
Page 14
2-4
www.hp.com
Hardware Reference Guide
Hardware Upgrades
5. To remove the front bezel, gently pull up all three tabs 1 on the
top of the bezel, then pull the bezel 2 away from the chassis.
Removing the Front Bezel
To reassemble the computer, reverse the above procedure.
Press down while replacing the access panel. Refer to the label on the
inside of the access panel for more information.
✎
To re-install the front bezel, insert the two bezel bottom tabs, then
rotate the front bezel forward to snap the three tabs on the top of the
bezel in place.
