On Screen Display
27
ENGLISH
The following functions of the AVR80
may be controlled through the Menu
Control System:
INPUT SELECTION : After reaching
the INPUT SELECTOR menu
(Figure #13), use the arrow keys on the
remote
q to select the desired input.
Remember that when a split listening
session is desired, select the
VIDEO
source first, followed by the AUDIO
source. To use the Tape Monitor, press
the down arrow button
¤ q to move
the on-screen cursor. Use the ‹ and ›
arrow buttons to turn the Tape Monitor
On or Off.
RECORD OUT SELECTION : After
reaching the REC OUT SELECTOR
menu (Figure #14) use the navigational
arrow keys to select the record source for
either
TAPE 1 or VCR 1 . Note that if
the current main input SOURCE is
chosen, two more lines will appear on the
screen to remind you which audio and
video sources are selected (Figure #15).
The
RECORD OUT SELECTION
effects the same as the ‘Copy’
Pushbuttons
 Ò on the front panel.
SURROUND MODE : After reaching
the SURROUND MODE menu (Figure
#16), use the navigational arrows q to
select the desired mode. When a mode is
selected that uses the surround channels,
you may change the rear channel
DELAY TIME at this menu.
TEST TONE : At this menu you may
adjust the speaker output levels. For
information on this procedure, refer to
the System Configuration section of this
Manual, page 18.
MULTI-ROOM SEL : For information
on configuring and using the multiroom
audio functions of the AVR80, consult the
appropriate section of this Manual, page
32.
SET UP MENU : For information on
using the Set Up menus, refer to the
System Configuration section of this
Manual.
> T A P E * S O U R C E *
V C R 1 * S O U R C E *
A U D I O * T U N E R *
V I D E O * L D *
R E T U R N T O M A I N M E N U
R E C O U T S E L E C T O R
Figure 15
> M O D E : T H X C I N E M A
D E L A Y T I M E : 2 0 m s
R E T U R N T O M A I N M E N U
S U R R O U N D M O D E
Figure 16
