Front Panel Information Display
5
ENGLISH
¡
“Visual” Indicator: These
indicators display which Video source
is being fed to the video monitor
output.
™
Test: This indicator flashes when
the output levels are being set using
the built in test signal generator.
£
Memo: This indicator flashes when
the Memo button is pressed when
entering presets and other information
into the tuner’s memory.
¢
Auto: This indicator signifies that
the Automatic Receiving mode (Stereo/
Mono) is in use for FM broadcasts.
∞
Tuned: This indicator lights when
an AM or FM station is properly tuned
and locked.
§
Stereo: This indicator lights when
an FM station is broadcasting in
stereo.
¶
Volume indication: The last two
indicators on the information display
indicate the volume level. Note that
0dB is the reference level, not an
indication that there is no output.
•
Tuner Frequency Indication:
When the tuner is in use, the main
Information Display will show the
preset channel number, if any, the
frequency band and the station
frequency. Indicators at the right side
of the display show
kHz when an LW
or AM station is tuned or MHz when
an FM station is tuned.
ª
Main Information Display:
This ten digit display shows
messages relating to the status, input
source, surround mode, tuner,
volume level or other aspects of the
unit’s operation.
‚
Multi: This indicator signifies that
the AVR80 is sending a program
source to a remote room location.
Note that it may be illuminated even
when the unit is “off” in the main
listening room, signifying that
operation continues at another
location. When a remote command is
being received via the Multi IR
connection, this indicator will flash.
⁄
Mode Status: These indicators
display the currently selected
surround mode.
¤
DISP: This indicator lights when
the FL display has been turned
off using the Display button
) to
remind you that the unit is still
turned on.
‹
Copy Indicators: The TAPE
COPY indicator lights when an input
other than the current source has
been selected to copy Tape 1. The
COPY1 VCR indicator signifies that
the input to VCR 1 is other than the
currently selected source.
›
P-Scan: This indicator flashes
when the stations programmed into
the tuner memory are being
automatically reviewed.
fi
Auto Memo: This indicator flashes
when the tuner is automatically
scanning for stations and entering
them into the preset memory.
fl
Signal Level Indication: This is a
visual indication of the strength of a
radio station signal. The more bars
visible, the stronger the station.
