System Configuration

17

ENGLISH

6. Press

SELECT

r

to move to the

next screen,

S E T U P MENU 1

.

(Figure #2).

7. The first item to be set is the Center
Channel Mode. The on screen

>

cursor

will already point toward this option
when you select the menu. Press the

or

buttons

q

to choose one of these

center channel options by moving the
cursor:

LARGE

: Choose this option if you are

using either a THX Certified speaker
system with a subwoofer or large size
full range center channel speaker.

SMALL

: Choose this option if the

center speaker is small sized.

NONE

: Choose this option if you are

not using a center channel speaker.

8. When the center channel speaker
selection is complete, press the

¤

button

q

to move to the next option. Note that

the on screen

>

cursor will move down to

SUBWOOFER

.

9. Press the

or

buttons

q

to choose

one of these options:

ON

: Choose this option if a Subwoofer

is installed, getting its signal from
‘subwoofer’ jack

µ

.

OFF

: Choose this option if no

Subwoofer is present.

10. Press

¤

q

once and then

SELECT

r

to move to

SET UP MENU 2

to

continue the set-up procedure. (Press

¤

twice and then

SELECT

if you prefer to

return to the

MAIN MENU

.)

11. At

SET UP MENU 2

(Figure #3) you

are able to establish settings for
multiroom operation and lock the
control settings. You may skip these
menus by pressing

¤

q

until the on

screen

>

cursor is next to

RETURN TO

MAIN MENU

and pressing

SELECT

r

.

12. If multiroom operation will be used,
the first option enables you to select the
method used for volume control. With the

>

cursor pointing to

MULTI RM VOL

press the

or

buttons to choose one of

these options:

VARIABLE

: Choose this option if

the volume control in the remote
rooms will be controlled by a remote
control and a sensor connected to the
AVR80 via the

MULTI IR

input on

the rear panel.

FIXED

: Choose this option if there

is no remote control link to the
remote rooms, or if you wish to have
the volume in these rooms remain at
a fixed, constant level.

13. When you have made your selection,
press

¤

q

to move to the next option,

SET LEVEL

. Press the

or

buttons

q

to set the volume in accordance with

the option chosen in the previous menu:

a. If you selected

VARIABLE

Volume Set, this option selects the
volume level at the remote rooms
when the system is first turned on in
those locations.

b. If you selected

FIXED

Volume

Set, this is the level that will remain
constant in the remote rooms.

I N P U T S E L E C T O R

R E C O U T S E L E C T O R

S U R R O U N D M O D E

T E S T T O N E

M U L T I R O O M S E L : O F F

S E T U P M E N U

M E N U O F F

M A I N M E N U

Figure 1

C E N T E R M O D E > L A R G E

S M A L L

N O N E

S U B W O O F E R O N

O F F

G O T O S E T U P M E N U 2

R E T U R N T O M A I N M E N U

S E T U P M E N U 1

Figure 2

M U L T I R M V O L

> V A R I A B L E

F I X E D

S E T L E V E L

X X d B

S E T U P L O C K L O C K

U N L O C K

R E T U R N T O M A I N M E N U

S E T U P M E N U 2

Figure 3

O F F > O N

T E S T T O N E

Figure 4
