High End Systems AXON - Manual (Page 279)

Axon Media Server User Manual 259
Appendix C:
Axon Media Server Specifications
Fixture mechanical, electrical, optical and component specifications are listed.
Mechanical
Fixture Dimensions: 65 mm x 89 mm x 528 mm (18.3 in x 3.5 in x 20.8 in)
Weight: 15 kg (33 lbs)
AXON
528mm (20.78")
425mm (16.73")
132.6mm
(5.22")
88.9mm
(3.5")
485mm (19.09")
465mm (18.30") 480mm (18.89")
Computer
Processor: Intel Pentium 3.2 GHz technology
Memory: 2 GB DDR2 RAM
Hard drive: Seagate SATA
Operating System: Windows XP embedded
Local Video Output allows viewing of CMA for Content Management and Configuration editing.
Connection: DVI with VGA Adapter
Operation
Control Options: DMX512, Art-Net
Compliances: CE
Video Connectors: : VGA—HD15, DVI, S-Video—mini-DIN
