2 • HP All-in-One
5
4
a
a b c d
a
b
b c
d e
Attach the control panel faceplate
(if not attached)
Load paper into bottom tray
a Position the control panel faceplate
over the buttons on the device.
b Press down fi rmly on all edges of the
faceplate until it snaps into place. Make
sure all buttons come through the holes in
the faceplate.
Load plain white paper in the bottom paper tray. Plain paper is needed for alignment.
Tip: If the paper is tabbed, make
sure the tab is towards you.
a Lift the output tray. b Pull out the photo tray. c Load the 4 x 6 inch (10 x 15 cm)
photo paper from the sample pack
with the glossy side down in the
photo tray.
6 Load photo paper
d Lower output tray and
push in the photo tray.
e Pull out the tray extender
and lift up the paper catch.
