5–16
5.7 Saving & Reusing Search Data
You can save the:
•
date and time for a motion search and its motion detection options for reuse.
- and/or -
•
lists of movement found in the video or edited lists, for further use with word
processing software or spreadsheets.
5.7.1 Repeating a Motion Search
! ! ! !68 To save the date, time, mask, motion options
1. You have the option of saving all preparation settings by clicking Save Cfg
(“save the configuration settings”). A dialog appears for saving the information
as a computer file.
2. Type a filename and select a folder, as needed.
3. Click OK. The information is saved in a file that has a .rmc extension.
! ! ! !69 To reuse a date and time for a motion search
1. In a Motion Search session, click the arrow in the Stream box to display a list of
the site’s cameras. You can see the arrow in figure 38 on p. 5–2.
2. Select a camera from the Stream list.
3. Click Load Cfg (“load the configuration settings”). A dialog appears for
selecting a computer file.
4. Select a file with a .rmc extension, and folder as needed.
5. Click OK.
6. Click Fetch, and then click Search.
Reusing settings on the same video generates the same motion detection report.
For a different report, change the motion options, the date and time or both.
5.7.2 Using a Report
A motion search report can be saved as a text file, then opened using a word processor,
for further enhancement.
! ! ! !70 To Save a motion Report as a text file
1. After obtaining a motion search report, click Save. A dialog appears for saving
the information as a computer file.
2. Type a filename and select a folder, as needed.
3. Click OK.
You have the option of filtering the magnitudes and/or trimming the report before
saving it as a text file. Only the items in the list are saved.
