1.80 1.80 TRANSMISSION / BRAKE - HYDRAULIC CIRCUIT
ITEM NO. DESCRIPTION PART NO.
1 Motor - Front Wheel Twinlock - 332cc/Rev 953686
2 Motor - Front Wheel Twinlock - 332cc/Rev 953682
3 Manifold - Front Transmission 953683
4 Valve - Solenoid - Work/Transport -
5 Valve - Pilot Operated - Diff Lock -
6 Relief Valve - Serial Lines - 80 bar -
7 Valve Solenoid - Diff Lock -
8 Relief Valve - Front Motor - 375 Bar -
9 Flow Divider - Front Wheels -
10 Valve - Pilot Operated - Diff Lock -
11 Shuttle Valve - Hot Oil Purge 953687
12 Relief Valve - Hot Oil Purge -
13 Relief Valve - Serial Line - 375 Bar 953710
14 Wheel Motor - Rear - 130cc/Rev 953685
15 Pump - Transmission - 52cc/Rev 953684
16 Relief Valve - Charge Pump - 29 Bar -
17 Relief Valves - Fwd/Rev - 350 Bar -
18 Oil Cooler 950606
19 Filter - Charge - 10 Micron 950597
20 Filter - Return - 10 Micron 924865
21 Hydraulic Oil Tank 953802
22 Check Valve - Transmission Fwd/Rev -
23 Suction Strainer - 125 Micron 950608
24 Valve - Brake 70-06-015W
25 Check Valve -
26 Orifice - 1.5mm Dia. -
