MAINTENANCE 1.47 1.47
ENGINE
Refer to the Engine Operator's Manual for maintenance information.
RUNNING IN PERIOD
Check wheel nut torque settings:
During first 50 hours of use and in addition to routine checks. Refer -
DAILY AND BEFORE USE. Check wheel nut torques twice a day.
Front axle wheel nut torque setting - 200 Nm.
Rear axle wheel nut torque setting - 54 Nm.
RUNNING IN PERIOD - AT FIRST 50 HOURS
Change the transmission oil filter: Unscrew and remove the bottom of the
transmission oil filter housing. Withdraw the filter element and discard. Refit
a new filter element (Hayter part no. 924708) and replace the housing.
ENGINE
1P953C17
1
2
3
1. Transmission Oil Filter.
2. Centre Cutterhead.
3. Hydraulic Oil Tank.
