SAFETY PRECAUTIONS 1.12 1.12
DECALS
Decal - Control Panel Part No: 994912
Location: Control Panel.
a) Ignition Switch
h) Cutters - Off
b) Engine Speed - Slow i) Cutters - Forward
c) Engine Speed - Fast j) Horn
d) Parking Brake - Engage k) Cutters - Lift
e) Parking Brake - Disengage l) Cutters - Hold
f) Weight Transfer - Control
m) Cutters - Drop/Float
g) Cutters - Reverse n) Hour Meter
Decal - Inclines Part No: 924857 (1)
Location: Centre Platform.
a) Warning - Travel slowly when turning and on slopes
b) Warning - Maximum slope without ROPS
c) Warning - Seat belt must be worn with a ROPS fitted.
d) Caution
e) Read operators manual
f) Stop engine/Remove ignition key before servicing or
maintenance
g) Beware of flying objects
h) Keep bystanders clear
Decal - Danger Latch Part No: 70-13-077
Location: LH / RH / Centre Arms
a) Caution
b) Stop engine/Remove ignition key before releasing or
operating safety latches
Decal - Diesel Part No: 70-13-078
Location: Fuel Tank
Diesel fuel only
Decal - Transmission Oil Part No: 70-13-071
Location: Oil Filler Bracket mounted behind Fuel Tank.
a) Transmission oil
b) Read and understand the operators manual.
0 - 19° 19°+
924857 (1)
a b c
d e f g h
IMPOR TANT / WICHTIG / BELANGRIJK
BEFORE USE : FILL MACHINE WITH RECOM-
MENDED OIL TO CORRECT LEVEL. FAILURE TO
DO SO WILL CAUSE SERIOUS DAMAGE AND IN-
VALIDATE WARRANTY .
AVANT L'UTILISA TION : IL EST IMPERATIF DE
REMPLIR LA TONDEUSE AVEC UNE HUILE
SPECIFIEE AU
NIVEAU EXACT POUR NE PAS
L'ENDOMMAGER SERIEUSEMENT ET ANNULER
LA GARANTIE.
VOR DEM GEBRAUCH: F ÜLLEN SIE DIE
MASCHINE MIT EMPFOHLENEM ÖL NACH, BIS
AUF DEN RICHTIGEN ST AND. DIE
NICHTBEACHTUNG DIESER INSTRUKTIONEN
KANN ZU ERNSTHAFTEN SCHADEN FÜHREN
UND DABEI WIRD DIE GARANTIE UNGÜLTIG.
VOOR GEBRUIK: VUL MACHINE MET
VORRGESCHREVEN OLIE TOT HET JUISTE
NIVEAU. HET NIET VOLGEN VAN DEZE
INSTRUKTIE LEIDT
TOT ERNSTIGE SCHADE EN
VERVAL VAN DE GARANTIE.
a b
a
b
n
