Electrical circuit diagram – Hayter Mowers T424 User Manual
Page 78
953910KG141004
1.78
1.78
ELECTRICAL CIRCUIT DIAGRAM
45.
Alternator/Regulator.
-
46.
Engine Temperature Sender (supplied with temp kit).
-
47.
Glow Plugs.
-
48.
Switch - Engine Overheat.
-
49.
Solenoid - Fuel
(SA 4259-12)
50.
Engine.
950950
51.
Hourmeter.
910850
52.
Switch - Return filter.
-
53.
Solenoids - Work/Transport Mode.
910627
54.
Fuse - Engine Glow plugs 60A
-
55.
Fuse - Main 60A
-
56.
Diode - Parking Brake
950868
57.
Diode - Seat Switch
950868
58.
Relay - Seat Switch
70-09-148
ITEM NO.
DESCRIPTION
PART NO.
