HP ProLiant ML115 G5 - Manual (Page 21)

Part Number 416121-001
Spare Kit 419029-001
Operational Input Voltage Range
(Vrms) 100 to 127 and 200 to 240 V auto ranging
Frequency Range (Nominal) (Hz) 50 to 60 Hz
Nominal Input Voltage (Vrms) 100 115 208 220 230 240
Max Rated Output Wattage Rating N/A 365 N/A N/A 365 N/A
Nominal Input Current (A rms) N/A 6 N/A N/A 3 N/A
Max Rated Input Wattage Rating
(Watts) N/A 553 N/A N/A 517 N/A
Max. Rated VA (Volt-Amp) N/A N/A N/A N/A N/A N/A
Efficiency (%) N/A >65% N/A N/A >65% N/A
Power Factor N/A N/A N/A N/A N/A N/A
Leakage Current (mA) 0.5mA (at
60HZ)
N/A N/A N/A N/A N/A
Maximum Inrush Current (A peak) N/A No
component
was damaged
and input
fuse shall not
blow
N/A N/A No
component
was
damaged and
input fuse
shall not blow
N/A
Maximum Inrush Current duration
(mS) N/A N/A N/A N/A N/A N/A
QuickSpecs
HP ProLiant ML115 Generation 5
Power Specifications
DA - 13013 Worldwide QuickSpecs — Version 10 — 12.15.2008 Page 21
