Huffy M732211 User Manual
Page 6
6
ID# M732211 05/06
PARTS LIST - See Hardware Identifier
NOTE: Hardware kit is designed for more than one style of basketball system.
Not all hardware will be used.
Item
Qty.
Part No.
Description
1
1
206657
Tank, (Black)
2
1
200628
Wheel Axle
3
2
226401
Wheel, 4” (Black)
4
1
908242
Top Pole Section
5
1
908246
Middle Pole Section
6
1
908247
Bottom Pole Section
7
1
202820
Rod, 3/8 O.D. x 4-3/4 Long
8
1
202822
Eyebolt, 3/8-16 x 2-1/2 Long
9
2
203063
Lock Nut, 3/8-16
10
2
906206
Tank Strut
11
1
201625
Bolt,Yellow Dichromate, 5/16-18 X 3.60
Long
12
6
203218
Washer, Flat, 5/16
13
1
203099
Lock Nut, 5/16-18
14
1
203493
Nut, Hex Head, 3/8-16 x 0.625 Long
15
2
205528
Bolt, Hex Flange, 5/16-18 x 1 Long
16
8*
203100
Nut, Hex Flange, 5/16-18
17
4
201651
Spacer .500 I.D. x .25 Long
18
2
206303
Washer 1/4 Flat
19
1
200627
Wheel Bracket
20
4
204558
Screw, Phillips, 1/4 x .375 Long, Type 25
21
1
Rim
22
1
206219
Cap, Pole Top 3”
23
1
202603
Washer, Nylon
24
2
203617
Plug Cap
Item
Qty.
Part No.
Description
25
1
522730
Label, Height Adjustment and Moving
26
1
Net
27
1
201160
Pawl Lever
28
1
801159
Ratchet
29
2
900846
Backboard Bracket
30
1
203472
Spring, Black, Slam Jam
31
1
200318
Bracket, Reinforcement, Slam Jam
32
1
900033
Bracket Slam Jam
33
4
202587
Spacer .520 I.D. x .750 O.D. x 1.0 Long
34
1
206305
Clevis Pin 1/4 x 2-3/8 Long
35
1*
206360
Bolt, Hex 3/8-16 x 2.65 Long
36
1
203796
T-Bolt, 3/8-16 x 5 Long
37
1
203470
Washer Flat, Slam Jam
38
7
206340
Lock Nut 1/2-13
39
1
203795
Nut, Special, Slam Jam
40
1
201125
Spring, Ratchet Return
41
4
206311
Spacer .520 I.D. x .750 O.D. x .50 Long
42
7
206304
Bolt 1/2-13 x 6-5/16 Long
43
4
908178
Elevator Tubes
44
2*
201129
Spacer .402 I.D. x .500 O.D. x 1.8 Long
45
1
201642
Spacer Plastic, .63 Long
46
1
281159
Handle
47
1
908176
Tube, Handle, Outer
48
1
908177
Tube, Handle, Inner
49
1
240017
Bolt, Hex 1/4-20 x 2.25 Long
50
2
203038
Bolt, Carriage, 5/16-18 x 2.75 Long,
51
4
203113
Bolt, Hex Flange, 5/16-18 x 2.5 Long
52
1
203365
Spacer, Rim
* You many have extra parts with this model.
