Huffy M732211 - Manual (Page 12)

12
ID# M732211 05/06
4.
5. Install wheel axle (2) through wheel carriage (19) and
install wheels (3) onto wheel axle (2) with spacers (17) as
shown. Insert pole assembly into tank assembly as
shown. Secure bottom pole (6) section to tank and wheel
carriage as shown. A deep socket is recommended.
8
7
6
Install rod (7) through holes in bottom pole section (6) and
eyebolt (8).
2
17
17
3
3
19
9
6
8
7
THE SPACER (17) WILL
FIT LOOSELY UNTIL
SECURED INTO THE
CAVITY OF THE BASE.
IMPORTANT!
TWO CAPABLE ADULTS
REQUIRED FOR THIS
PROCEDURE. FAILURE TO
FOLLOW THIS WARNING
COULD RESULT IN SERIOUS
INJURY AND/OR PROPERTY
DAMAGE.
WARNING!
IMPORTANT!
The Warning Label
should be facing
towards the front.
DO NOT OVER
TIGHTEN
IMPORTANT!
