August 1, 2008
Page 51 Heat & Glo · Tiara Petite B · 7026-101K
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D. Service Parts List
(cont’d.)
TIARA PETITE B
(NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-04
Ending Manufacturing Date:
Item
#
Part Description
Alphabetical Order
SKU
9 Adapter, DV 7000-162
2 Air Shutter Assembly 7016-017
25 Back Shield 7016-140
3 Baffl e 7016-125
4 Baffl e Back 7016-126
Blower Assembly BK-GAS
7 Blower Shroud Back 7016-132
10 Blower Shroud Top 7016-118
1 Bulkhead with Flex Tube 7000-156
21 Burner with Neck Assembly BRNR-TPB
Burner Stop 7010-152
Burner Support 7016-120
Cable/Switch Assembly 230-1900
Component Pack Assembly, Matte Black (includes warranty card, ON/OFF valve, mineral wool, leveling assembly, snap disc bracket,
restrictor, owner’s manual, fasteners, and Touch-up Paint.) MBK: 7026-003
BR: 7026-008
CES: 7026-011
CTO: 7026-012
Conversion Kit, LP LPK-TPB
Conversion Kit, NG NGK-TPB
5 Damper Assembly 7016-006
32 Door Frame 7016-117
14 Door/Glass Assembly GLA-TPB
15 Door Retainer 7016-134
Flex Line 3/8 Flare x 22L 7000-197
Flue Collar 7016-122
8 Flue Shield 7016-130
29 Front See page 52
6 Gasket, Adapter Elbow 460-0610
33 Glass Assembly Only 7016-023
19 Ignition Module 230-1880
17 Knob, Extension, HI/LO 571-533
16 Knob, Extension, ON/OFF 571-534
13 Latch, Draw 229-0640
30 Log Set Assembly LOGS-TPB
ON/OFF Valve 15697A
Orifi ce Insert #49 (NG) 842-1220
Paint, Touch-up, Espresso TOUCHUP-CES
Paint, Touch-up, Matte Black 7000-304
Paint, Touch-up, Tuscan Olive TOUCHUP-CTO
