Heat & Glo Fireplace TIARAP-CES - Manual (Page 45)

August 1, 2008
Page 45 Heat & Glo · Tiara Petite B · 7026-101K
12
Reference Materials
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For clearances to combustibles refer to Section 3.
Location Inches Millimeters Location Inches Millimeters
A 27-3/8 695 D 17-3/8 441
B 18-1/8 460 E 22-3/4 578
C 15-3/8 384 F 16-1/4 413
Figure 12.1 Appliance Dimensions
B
A
C
D
E
F
