PREPARATION FOR USE
16
PREPARATION FOR USE
CABLE CONNECTIONS
For some of the most common types of connections, see the following drawings. Use only one
connection. For any further complex connections, please contact your local dealer or other
qualified persons. (You may need additional accessories which are not supplied).
1 Disconnect the antenna or cable from your TV.
2 Connect the antenna or cable to the ANT.IN jack of your VCR.
3 Connect one end of the coaxial cable (supplied) to the ANT.OUT jack of your VCR.
4 Connect the other end of the coaxial cable (supplied) to the UHF/VHF antenna jacks.
