HA113A1 #588 (installation) configuration, I/O card cage
and I/O cards) optional Deployment
Manager
I/O cage is field installed
(requires installation option)
I/O Cards Depends on I/O card being ordered Validate there are sufficient
slots within existing card cage No TCE Manager, but
optional Deployment
Manager
I/O cards are field installed
into card cages (included in
hw price)
Redundant PDCA A5800A Validate there is an open slot
for redundant PDCA No TCE Manager, but
optional Deployment
Manager
Redundant PDCA are field
installed (included in hw
price)
Cell Board into existing partition A6866A Serial number
Existing partition
configuration (cell placement,
iCOD, OE license type) No TCE Manager, but
optional Deployment
Manager
Installation does not include
any partition reconfiguration.
New Partition A6866A Serial number
Existing partition
configuration (cell placement,
iCOD, OE license type)
Media requirements (i.e. new
DVD, SCSI converter, etc.) TCE Manager optional,
Deployment Manager
recommended
High-level design,
recommended detailed design
Partitions are field installed
(included in hw price)
Installation does not include
any partition reconfiguration
Benefits of Optional Services Benefits of Optional Services Benefits of Optional Services Benefits of Optional Services
Optional Service Optional Service Optional Service Optional Service Benefits Benefits Benefits Benefits
TCE Manager for adding cells into existing partition or creating a new
partition Enhance TCE by coordinating all of HP's resources focused on fulfilling the
customer's solution.
Detailed Design for component add on and Superdome 16-way to 32-way
upgrade Ensures a properly configured solution with the add on or upgrade. Provides
pre installation planning for partition reconfiguration and operating
environment installation. Minimizes impact to production and reduces
customer risk.
Deployment Manager for add-on component Extend Total Customer Experience by proactively managing/scheduling all
field resources required to install and integrate the hardware and to re
partition the environment, if required.
Add-on Installation Add-on Installation Add-on Installation Add-on Installation
Services
Services Services Services
I/O cards are the ONLY Superdome add on components that are customer installable. However, HP assisted
installation is an available option.
All other Superdome add on components (cell boards, memory, I/O chassis, PDCA) require HP installation.
Required installation is available either as a required option or already included in the hardware purchase price.
Installation options are ordered one per installed product.
The add-on installation product is as follows:
H4725A #588: PCI-X chassis and PCI-X Core I/O installation
QuickSpecs HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way, HP Integrity Superdome Servers: 16-way, 32-way,
and 64-way and 64-way and 64-way and 64-way
Upgrades
