12790_div.html

HP BladeSystem c7000 Enclosure QuickSpecs:

http://h18000.www1.hp.com/products/quickspecs/12810_div/
12810_div.html

HP Smart Array E200i
Controller

Disk Drive and Enclosure
Interface

3G SAS (Serial Attached SCSI)

1.5G SATA (Serial Advanced Technology Attachment)

Cache Memory Speed DDR-1/266 MHz provides up to 4.2 GB/s maximum bandwidth.

Server Interface

x4 2.5G PCIe provides 2GB/s maximum bandwidth.

SAS Speed

x2 3G SAS provides 600MB/s maximum bandwidth.

Cache Memory

40-bit 64 MB or 128 MB cache: ECC protection, battery-backed, and
transportable

Logical Drives SupportedUp to 32 logical volumes

Maximum Logical Drive
Capacity

144GB (2 x 72GB)

Host Memory Addressing

64-bit, supporting greater than 4GB server memory space

RAID Support

RAID 5 (Distributed Data Guarding) requires 128MB BBWC option

RAID1, 1+0 (Striping & Mirroring)

RAID 0 (Striping)

Upgradeable Firmware Upgradeable Firmware

Embedded NC373i
Multifunction Gigabit
Server Adapter

Network Processor

Broadcom 5708S

Data Transfer Method Four lane (x4) PCI Express

Network Transfer Rate 2000 Mb/s full duplex (theoretical maximum value)

NOTE: The Gigabit Ethernet adapters above transmit from the server at 2000
Mbps, full duplex per port only. For more information, see the "Network
Controller" segment in the Standards Features section.

IEEE Compliance

802.1p, 802.1Q, 802.3, 802.3ad, and 802.3x

Standard Features

TCP/IP offload engine (TOE) for Microsoft Windows 2003
iSCSI Boot for Linux
Optional accelerated iSCSI
9K jumbo frames
TCP/IP checksum offload (TCO)
Large send offload (LSO)
Interrupt coalescence
Dual address cycles (DAC)
Wake-on-LAN (WOL)
Pre-boot execution environment (PXE)
ProLiant Teaming including Network Fault Tolerance, Transmit Load
Balancing, and Switch-Assisted Load Balancing
IPv6 packet transmit and receive (excluding all offload capabilities);
IPv6 aware SNMPv1 agents for Microsoft Windows

QuickSpecs

HP ProLiant BL460c Server Blade

Technical Specifications

DA - 12518 Worldwide QuickSpecs — Version 35 — 4.27.2009

Page 30
