91 Embedded Web Server User Guide
5
Monitoring Products
The Monitor page is used to access information about the product including port
and node information as well as critical information about performance. Key tasks
you can perform to troubleshoot problems from the Monitor page are:
■ Monitoring Ports on page 91
■ Accessing Port Statistics on page 94
■ Reviewing the Event Log on page 98
■ Viewing Node List on page 100.
Monitoring Ports
You can obtain information about ports from the Port List and Port Stats tab
views.
Port List
Choose Monitor on the navigation panel. The Port List tab view displays
(
Figure 30 ). The Port List tab view provides the following information including
information on the port state:
■ Port # — The number of the port.
■ Name — Displays the port name as configured through the Configure Ports
tab.
