100 Embedded Web Server User Guide
Clearing Event Log Entries
Note: Before clearing the event logs, make sure the logs are not needed for
troubleshooting. Once the event log is cleared, the data cannot be retrieved.
To access this option, choose Monitor and choose the Log tab. Choose Clear
Event Log Entries to clear the event logs for the product. A message displays
stating that the operation has been performed successfully.
Clearing the System (Product) Error Light
To access this option, choose Monitor, and then choose the Log tab. Click Clear
System Error Light to clear the ERR (error) LED on the product’s front panel.
(The ERR LED remains illuminated as long as an event like a FRU failure is
active.) A message displays stating that the operation has been performed
successfully.
Viewing Node List
Choose Monitor on the navigation panel. Choose the Node List tab; the Node
List tab view displays (
Figure 33 ). The Node List tab view displays information
about all node attachments or N_Ports that have logged into existing F_Ports on
the product. All data is dynamically updated as the nodes log in and log out. To
update the information in the view, click the Refresh button.
Figure 33: Node List tab view
