DIVA T/A ISDN Modem User’s Guide 108
PHONE LEDs
1, 2 LEDs
LED Indicator Description
Off
•
No call activity on the specified voice channel.
Flashing
•
An outgoing or incoming connection is being
established on the specified voice channel.
Steady
•
There is a connection on the specified voice
channel.
SERIAL LEDs
TX-RX LED
LED Indicator Description
Off
•
There is no data being transferred on the serial
port.
On
(intermittent)
•
Data is being transferred on the serial port.
DTE LED
LED Indicator Description
Off
•
There is no call activity on the specified serial
port.
Flashing
•
An outgoing or incoming connection is being
established on the serial port.
Steady •
This indicates there is a data connection.
•
With AO/DI, this indicates the B-channels are off
and only the D-channel is being used for your
data connection.
