0-3 1" Ultra3 Hot Plug Drive Bays
A 1.44-MB Floppy Drive
B Slimline CD/DVD-ROM Drive, Hot Pluggable, in Universal Media Bay
C Universal Media Bay Eject Button
Drive Support Drive Support Drive Support Drive Support
Quantity Quantity Quantity Quantity
Supported
Supported Supported Supported
Position Position Position Position
Supported
Supported Supported Supported Controller Controller Controller Controller
Integrated Media Integrated Media Integrated Media Integrated Media
Integrated 1.44-MB
Diskette Drive
Up to 1 A Integrated
Slimline CD/DVD-ROM
Drive (8X/24X)
Up to 1 B Integrated IDE
Hard Drives Hard Drives Hard Drives Hard Drives
Ultra320 Hot Pluggable Drives Ultra320 Hot Pluggable Drives Ultra320 Hot Pluggable Drives Ultra320 Hot Pluggable Drives
Quantity Quantity Quantity Quantity
Supported
Supported Supported Supported
Position Position Position Position
Supported
Supported Supported Supported Controller Controller Controller Controller
1-inch 1-inch 1-inch 1-inch
146.8-GB 10,000 rpm
72.8-GB 10,000 rpm
36.4-GB 10,000 rpm
72.8-GB 15,000 rpm
36.4-GB 15,000 rpm
18.2-GB 15,000 rpm Up to 4 0-3 Integrated Smart Array 5i Controller
Smart Array 532 Controller
Smart Array 5304/256 Controller
Smart Array 641 Controller
Smart Array 642 Controller
64-Bit/133Mhz Dual Channel Ultra320 SCSI Adapter
NOTE: NOTE: NOTE: NOTE: All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives require an optional U320 Smart Array Controller or
U320 SCSI HBA to support U320 transfer rates.
External Storage External Storage External Storage External Storage
Quantity Quantity Quantity Quantity
Supported
Supported Supported Supported
Position Position Position Position
Supported
Supported Supported Supported Host Controller or Adapter Host Controller or Adapter Host Controller or Adapter Host Controller or Adapter
Modular Smart Array 30 Family Up to 13 External Smart Array 5304/256 Controller
Smart Array 6402/128 Controller
Smart Array 6404/256 Controller
Smart Array 642 Controller
64-Bit/133-MHz Dual Channel Ultra320 SCSI Adapter
64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter, Alternate OS
Modular Smart Array 500
System
1 External Smart Array 532 Controller (used as Host Bus Adapter)
Please see the Modular Smart Array 500 QuickSpecs for the latest list of
supported HBAs:
http://www.hp.com/go/msa500
Modular Smart Array 1000 Please see the
Modular Smart Array
1000 QuickSpecs
below to determine
configuration
requirements External Please see the Modular Smart Array 1000 QuickSpecs (URL below) for the latest
list of supported HBAs
Modular Smart Array 1000: http://h18000.www1.hp.com/products/quickspecs/11033_div/11033_div.HTML (Worldwide)
http://h18000.www1.hp.com/products/quickspecs/11033_na/11033_na.HTML (North America)
