Interleaved 2 of 5 message length, Interleaved 2 of 5 message length -11 – Hand Held Products 2D IMAGER 4800P User Manual
Page 65
6 - 11
When Check Digit is set to Validate and Transmit, the imager only reads
Interleaved 2 of 5 bar codes printed with a check digit, and will transmit this digit
at the end of the scanned data.
Default = No Check Digit.
Interleaved 2 of 5 Message Length
Scan the bar codes below to change the message length. Refer to
(page 6-2) for additional information. Minimum and
Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80.
Validate, but Don’t Transmit
* No Check Digit
Validate and Transmit
Minimum Message Length
Maximum Message Length
