16
Specifications of KP-FD140F/F140F/FD32F/F32F/F83F are showing.
KP-FD140F/F140F KP-FD32F/F32F KP-F83F
1) Imaging device 1/2-inch interline CCD 1/3-inch interline CCD
Total pixels 1434 (H) x 1050 (V) 692(H) x 504(V) 1079(H) x 789(V)
Effective pixels 1392 (H) x 1024 (V) 656(H) x 492(V) 1034(H) x 779(V)
Pixel size 4.65μm (H) x 4.65μm (V) 9.9μm (H) x 9.9μm (V) 4.65μm (H) x 4.65μm (V)
Color filter RGB primary color mosaic filters (FD140/FD32F)
2) Scanning system Progressive scan
3) Synchronization Internal / external (auto selection)
4) Video signal output
Interface IEEE1394.b (FireWire800)
Protocol IEEE1394-based Digital Camera Specification Version 1.31 compliant
Transfer rate 800 / 400 / 200Mbps
RGB24 / RGB48 / YUV4:2:2 / RAW8 / RAW１6 for FD140F/FD32F Image format
MONO8 / MONO16 for all model
Image size 1360(H) x 1024(V) 656(H) x 492(V) 1024(H) x 768(V)
1280(H) x 960(V) 640(H) x 480(V) 800(H) x 600(V)
1024(H) x 768(V) 640(H) x 480(V)
800(H) x 600(V)
640(H) x 480(V)
Frame rate 15fps (1360 x 1024) 60fps (656 x 492) 30fps (1024 x 768)
5) Standard sensitivity 2000lx F5.6 : KP-FD32F/F32F, 2000lx F8 : KP-FD140F/F140F/F83F
6) Minimum illumination 10lx (F1.4 Gain Max) : KP-FD32F/F32F, 5lx (F1.4 Gain Max) : KP-FD140F/F140F/F83F
7) Gain Auto / Manual (0dB to 18dB)
8) Electric shutter Auto (AES) / Manual (VARIABLE) 1/100,000 second to 10 second
9) External trigger shutter
Mode Fixed shutter (Mode0), One trigger (Mode1)
Reset control (Mode14), VD Sync (Mode15)
Input Via IEEE1394 cable (Software trigger ) Our company original method (Hardware trigger)
10) Power supply Approx. 4.1W (DC+12V) Approx. 3.5W (DC+12V) Approx. 3.2W (DC+12V)
11) White balance ATW / MANUAL / One-Push (FD140F/FD32F)
12) Gamma OFF／LUT
13) Masking OFF / ON (6 color independent masking)
14) Saturation Adjustable (FD140F/FD32F)
15) Sharpness Adjustable
16) Brightness Adjustable
17) Time stamp OFF/ON
18) Cycle timer sync OFF/ON
19) Daisy chain Possible. Even if there is no repeater. If two are connected, the frame rate become half.
20) Lens mount Ｃ mount （Flange-back adjustment)
21) Power supply DC+8V to +30V (Via IEEE1394 cable)
22) Ambient temperature
Operating -10℃ to ＋50℃, 30 to 80%RH
Note: If operated continuously, be sure to use at 0℃ to +40℃ (104F)
for long term stable performance.
Storage -20℃ to ＋60℃ / 20 to 90%RH
23) Vibration endurance 68.56m/s 2 (10 to 200Hz 30 minutes each on XYZ axes)
*Please do not add the strong vibration over long time.
24) Shock endurance 490.3m/s 2 (vertical, horizontal, once each faze)
25) Dimensions 44(W) x 44(H) x 54(D)mm (not including lens)
26) Mass Approx. 130g (not including lens)
27) Standard composition Camera, CD-ROM (Operation manual, Driver, SDK),Composition
Specifications
