Page 12
2
Section name and functions
Connector
Signal connection to IEEE1394.b (PORT1/PORT2) Viewer Soft Setting (PORT1/PORT2)
1 TPB-
*Programmable
I/O
In
Out
2 TPB+
Trigger
○
○
3 TPA-
VD
○
○
4 TPA+
SPECIAL DATA
Strobe (Flash pulse)
×
○
5
TPA (R)
SHIELD GND
6 VG
POWER
GND
7
I/O
* Programmable I/O
8 VP
POWER
+12V
9
TPB (R)
SHIELD GND
Camera / Tripod adaptor
mounting screw holes
Camera / Tripod adaptor
mounting screw holes
Lens mount
(C mount)
*1
When power is supplied from IEEE1394,
check for proper current and voltage.
IEEE1394 connectors
*1
Connect to IEEE1394 connector
of PC using IEEE1394 cable.
POWER/STATUS LED
LED
Green
Yellow
Power ON
Light Off
Light off
Transmission
Blink Off
Blink On
Transmission pause Blink On
Blink Off
ＰＬ
ＡＴ
Ｅ
，
Ｒ
Ａ
Ｔ
Ｅ
Ｄ
Ｐ ＯＷＥ Ｒ/ＳＴ Ａ Ｔ ＵＳ
Ｐ ＯＲＴ ２
Ｐ ＯＲＴ １
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
PORT2
PORT1
