10

Video format

1. KP-FD140F/F140F

A. Fixed format

Frame Rate

Format

Mode

Image Size

Color Coding

30

15

7.5

3.75

1.875

3

640 x 480

YUV(4:2:2)

4

640 x 480

RGB

5

640 x 480

YMONO8

0

6

640 x 480

YMONO16

0

800 x 600

YUV(4:2:2)

1

800 x 600

RGB

2

800 x 600

YMONO 8

3

1024 x 768

YUV(4:2:2)

4

1024 x 768

RGB

○(*)

5

1024 x 768

YMONO 8

6

800 x 600

YMONO 16

1

7

1024 x 768

YMONO 16

0

1280 x 960

YUV(4:2:2)

○(*)

1

1280 x 960

RGB

○(*)

2

1280 x 960

YMONO 8

2

6

1280 x 960

YMONO 16

○(*)


B. Free format (Format7)

Format

Mode

Image Size

Color Coding

Packet Size [Byte]

1360 x 1024

YUV(4:2:2)

8192 (*)

6144 (*)

4096

2048

1360 x 1024

RGB

8192 (*)

6144 (*)

4096

2048

1360 x 1024

YMONO 8

8192 (*)

6144 (*)

4096

2048

1360 x 1024

YMONO 16

8192 (*)

6144 (*)

4096

2048

1360 x 1024

RAW8

8192 (*)

6144 (*)

4096

2048

1360 x 1024

RAW16

8192 (*)

6144 (*)

4096

2048

7

0

1360 x 1024

RGB48

8192 (*)

6144 (*)

4096

2048


KP-FD140F only

(*) required S800 data transmission rate.
