APPENDIX
System Defaults
The two tables in this section show the factory default settings for the Video Inputs, Video Sources and Video Display Aspect Ratios. These tables give you the
complete picture on the AVR 745’s initial settings. You may then decide whether any item needs to be changed so that it is more appropriate for your specific
installation. Any of the settings shown may be changed as shown in the pages of the System Configuration section of this manual (pages 20 to 32).
Table 1: Video Input Defaults
INPUT
AUDIO VIDEO COMPONENT
TRIGGER
2
RECORD AUTO-POLL
INPUT
INPUT
INPUT
VIDEO INPUT
SETTING
OUTPUT
SOURCE TYPE
Video 1
ANALOG
AUTO
COMPONENT 1
ON
ANALOG
ON
VCR
Video 2
ANALOG
AUTO
COMPONENT 2
ON
ANALOG
OFF
CABLE DIGITAL
Video 3
OPTICAL 1
AUTO
COMPONENT 1
ON
ANALOG
ON
CABLE ANALOG
Video 4
OPTICAL 4
AUTO
COMPONENT 2
ON
ANALOG
ON
SATELLITE DIGITAL
DVD
COAX 1
AUTO
COMPONENT 3
ON
ANALOG
OFF
DVD
HDMI 1
HDMI 1
HDMI 1
---
ON
DSP DOWNMIX
OFF
*
HDMI 2
HDMI 2
HDMI 2
---
ON
DSP DOWNMIX
OFF
*
Tuner
ANALOG
AUTO
COMPONENT 1
ON
ANALOG
---
*
CD
ANALOG
AUTO
COMPONENT 3
ON
ANALOG
OFF
*
Tape
ANALOG
AUTO
COMPONENT 1
ON
ANALOG
OFF
*
DMP/The Bridge
ANALOG
HDMI 1
COMPONENT 1
ON
ANALOG
---
*
6/8 CH Direct
ANALOG
HDMI 1
COMPONENT 1
ON
ANALOG
---
*
USB
---
HDMI 1
COMPONENT 3
ON
DSP DOWNMIX
---
*
Table 2: Video Source Defaults
FEATURE
DVD
VCR
CABLE DIG
SAT DIG
SAT ANALOG
CABLE ANALOG
CAMERA DIG
CAMERA ANALOG
Noise Reduction
OFF
ON
OFF
OFF
ON
ON
OFF
ON
X-Color Suppressor
ON
ON
ON
ON
ON
ON
ON
ON
DCDi Interpolation
ON
ON
ON
ON
ON
ON
ON
ON
Film Mode Detect
ON
ON
ON
ON
ON
ON
ON
ON
Film Mode Edit Detect
ON
ON
ON
ON
ON
ON
ON
ON
Composite Video Enhancement
ON
ON
ON
ON
ON
ON
ON
ON
VCR Sync Time Enhancement
ON
ON
ON
ON
ON
ON
ON
ON
System Default and Personal Settings Worksheets
The worksheets in this section show the system defaults for the global settings on your AVR 745. Once your system is configured manually, or through the
use of EzSet/EQ II, where applicable, we recommend that you use the “Your System Settings” column to record your personal preferences so that they may be
restored in the event the AVR’s memory is lost due to an extended power outage, system upgrade, processor reset, or other major service to your unit.
Additional copies of this worksheet may be downloaded from the Harman Kardon web site at www.harmankardon.com
Worksheet A: Video Monitor and Aspect Ratio Defaults and Settings
Feautre/Display Type
System Default
Your System Setting
Display Interface
Analog
HDMI Audio Out
Off
CRT
4:3
Front Projection
4:3
Rear Projection
4:3
Plasma (PDP)
16:9
DLP™
16:9
LCD
16:9
*: User should change setting to match input type.
